Specification
Pickup Device:
1/3 inch interline transfer B/W CCD
Picture Element:
768x494 (EIA)
752x582 (CCIR)
Horizontal resolution: 560 TV lines
Sensitivity:
0.01 lux/F=1.2
S/N ratio:
Over 48 dB
Electronic shutter:
1/60(1/50)~1/100,000 sec
Auto. Iris:
Video / Direct Drive switch
Flickerless:
On/Off
Back Light Comp:
On/Off
Electronic Shutter: On/Off
Auto Gain Control: On/Off
Line Lock:
On/Off
Audio:
Yes
Gamma Correction:
> 0.45
Video output:
1.0Vp-p,75 ohm(BNC)
Sync. Mode: 1. Line-Locked with LL on
2. Internal Sync. With LL off
Lens Mount:
C/CS mount back focus adjustment
Power source:
90-260VAC (EQ150)
12VDC/24VAC (EQ150A)
Dimension:
51x57x140.2mm
Operating Temperature: 0
to +50
Power Consumption
5W max
