TECHNICAL DATA
DIMENSIONS
Height Width Depth
Overall 1462mm (nominal) 498mm 600mm
(from elbow
to front of door panel)
Height to hotplate 907mm nominal -
see important note 'Location of the Appliance' (see Page 34).
Space for fixing at hotplate level 2mm minimum 600mm
clearance Nominal
Space for fixing above hotplate level 100mm each side
of appliance
Minimum space above grill 500mm
Minimum distance from rear wall 20mm
Weight of appliance 50.0kg
CONNECTIONS
Gas Rear left hand side of appliance at hotplate level
Rc½ (½" B.S.P. female)
Electric None
IGNITION
Spark Generator APCO 6BG6893
Battery 1.5 volt AA size
GRILL Natural Gas L.P. Gas
Heat Input 3.3kW (11263 Btu/h) 3.55kW (255g/h)
Injector Marking 138 95
32
