12
1. Cut one piece of line to recommended length.
.080 (2.0
mm
)
dia
. – 10’ (3
m
)
.095 (2.4
mm
)
dia
. – 10’ (3
m
)
nylon lIne replaCemenT
2. Align arrows on top of knob with openings in eyelets.
3. Insert one end of trimmer line into an eyelet, and push line equal
distance through trimmer head.
4. Hold trimmer head while turning knob clockwise to wind line onto
spool until about 5” (13 cm) of each line remains exposed.
T
rImmer head Is now fully loaded and ready for operaTIon
.
NOTE:
Trimmer head is pre-wound with .095" (2.4mm) Crossfire™ trimmer
line.
Wear Indicators
Wear Indicators
IMPORTANT
When the wear indicators located at the bottom of the Speed-Feed ® head are worn smooth, replacement of the cover or the
entire Speed-Feed ® head is required.
