14
GB
E 1. Release the chain brake by shift-
ing the brake arm over against
the front grip (8).
2. Place the electric chainsaw onto
a solid, flat surface. It must not
contact any objects.
3. Connect the device to the mains
voltage.
4. Hold the electric chainsaw firmly
with both hands, with the right
hand on the rear grip and the left
hand on the front handle. Thumb
and finger must close securely
over the handles.
5. Turn on the electric chainsaw.
6. Activate the chain braking lever
(3), with running motor, with the
left hand. Chain should stop
abruptly.
7. Once the chain brake is work-
ing properly, release the on/off
switch and the chain brake.
If the chain brake does not func-
tion correctly, you must not use
the electric chainsaw. A slack
saw chain leads to danger of in-
jury.
Return the electric chainsaw to
our Service-Center for repair
(see P. 173 for our address).
Checking the oil automatic
system
Check the oil level and the oil automatic
system before commencement of work.
• Switch on the chainsaw and hold it
above a bright background. The saw
must not touch the ground.
If an oil trace can be seen, the chainsaw
is working trouble-free. Select the oil regu-
lator to prevent oil droplets forming, but
also to prevent the chain from ever run-
ning dry. When the chainsaw is put away
in storage, set the oil regulator to zero.
J 4. Clean the oil passages of the
chain bar ( J 26), in order to
guarantee a trouble-free, auto-
matic oiling of the saw chain dur-
ing operation.
Changing the saw bar
F 1. Switch the saw off and unplug it
from the mains.
2. Lay the saw on a flat surface.
3. Loosen the safety bolt (15) un-
derneath the tensioning unit.
Turn the fastening bolt (14) anti-
clockwise to remove the sprock-
et chain wheel covering (16).
4. Remove the saw bar and saw
chain. To remove the guide bar
(4), raise it to an angle of ap-
prox. 45 degrees. This will make
it easier to take the saw chain
(5) off the sprocket (23).
5. To fit the new bar, place the bar
onto the bar bolt with the ten-
sioning plate pointing outwards
(23).
Fitting the saw chain
G 1. Switch the saw off and unplug it
from the mains.
2. Spread the chain (5) out into a
loop with the cutting edges run-
ning clockwise .
