Page 36

C-30
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
Touchmonitor Specifications
Table C.1
18.1" LCD Touchmonitor (ET182XL-XXWB-1) Specifications
Display Type
Active matrix, thin film transistor
(TFT), liquid crystal display
Size
18.1-inch diagonal
359.040 x 287.232 mm useful screen
area
Pixel Format
1280 x 1024
Touchscreen
0.125-inch IntelliTouch and
AccuTouch, anti-glare
IntelliTouch or AccuTouch
Colors
16 million with dithering
Display
Brightness
IntelliTouch: 210 cd/m² Max.
AccuTouch: 188 cd/m² Max.
Back-light Lamp
Life
40,000 hours at 50% brightness
typical
Viewing Angle
Horizontal
Vertical
-85~85 or 170 degrees total
-85~85 or 170 degrees total
Contrast Ratio
400:1 typical
Display Response
Time
16 ms (tr) /7 ms (tf)
Environmental
Operating Temp
Storage Temp
Humidity
10°C to 40°C
-20°C to +60°C
80% non-condensing AT
95% IT
Mechanical
Weight
Size
28 lbs. maximum approx. weight
for IntelliTouch and AccuTouch
See drawings on page C-34.
Electrical
Input Video
Input Power
Power Dissipation
VGA/SVGA/XGA/SXGA analog or digital video
Main Adapter:100-240VAC,50/60Hz /LCD:12VDC 4A
Universal
Speakers
8 ohms, 2 watt per speaker
Agencies
Safety & EMC
UL, cUL, UL-AR/S, IEC60601-1, MPR II
FCC-B, CE, VCCI, C-Tick, ICES-03, CB
