Page 9

Elan Digital Systems Ltd.
9
CF232 USER’S GUIDE
As a simple rule of thumb, using the standard serial drivers on a fast
PC will allow throughput rates of 400-600KBits/sec although these
rates can’t be guaranteed and will be application specific
.
5.7 BAUD RATE SETTINGS
The table below illustrates the common baud rate values available
for each of the baud rate multiplier switch positions:
HOST SETTING
SWITCH = x1
SWITCH = x8
300
300
2400
1200
1200
9600
2400
2400
19200
4800
4800
38400
9600
9600
76800
19200
19200
153600
38400
38400
307200
57600
57600
460800
115200
115200
921600
