EverFocus ED330 User Manual
Page 4
INSTALLATION
This section cover simple steps and detail installation. Please follow instruction for preventing
any unnecessary damage.
Simple Steps:
1. Open Camera Cover
2. Mount Camera on Ceiling or Wall
3. Connect power, video
Detail installation:
1. Open Camera Cover
Turn Clockwise to open it gently. Be careful not to damage the lens.
2. Mount the camera on ceiling or wall. Refer dimension b for drilling
dimension.
