S1c/s1h specifications and dimensions, S2c specifications and dimensions – EMI Volts/HZ/pH User Manual
Page 22
www.enviromaster.com
Side Discharge Condensers
22
moUnting DimenSionS
model Size
a
b
C
D
S1C/S1H9, S1C/S1H2
4 ⅝”
14
11
/
16
”
3”
12
7
/
16
”
S1C/S1H8, S1C/S1H2
4 ⅝”
22
11
/
16
”
3”
12
7
/
16
”
S1C3, S1C6
7”
23
15
/
16
”
3”
12
7
/
16
”
Easy access interconnects
on back of unit
1/2” Diameter Lag Holes
a
a
b
D
C
SoUnD Data
Size btuh
dba
Heat
Pump &
Cool
09
59
12
59
18
62
24
63
Cool
Only
30
68
36
68
S1C/S1H SpeCiFiCationS anD DimenSionS
SHipping WeigHt
Size btuh
lbs.
9-12
98
18-24
156
30-36
210
a
b
C
Electrical
connections
pHYSiCal DimenSionS
model Size
a
b
C
S1C/S1H9
24"
15"
36"
S1C/S1H2
24"
15"
36"
S1C/S1H8
32"
15"
36"
S1C/S1H4
32"
15"
40"
S1C/S1H3
38”
15”
44”
S1C/S1H6
38”
15”
48”
SoUnD Data
model Size
dba
99
64
22
65
92
65
pHYSiCal DimenSionS
model Size S2C
a
b
C
99
32"
15"
36"
22, 92
32"
15"
40"
SHipping WeigHt
model Size
lbs.
99
129
22
167
92
157
S2C eleCtriCal SpeCiFiCationS
Capacity
Volts/HZ/phase
Fan mtr.
Compressor
total
ampS
mCa
HaCr
brKr
min.
Volt
Circuit #1
Circuit #2
ampS
Hp
rla
lra
rla
lra
9900
208-230/60/1
0.8
0.125
3.5
19
3.5
19
7.8
8.7
15
197
9200
208-230/60/1
0.8
0.125
3.5
19
4.5
21
8.8
10.0
15
197
2200
208-230/60/1
0.8
0.125
4.5
21
4.5
21
9.8
11.0
15
197
moUnting DimenSionS
model Size S2C
a
b
C
D
99, 92, 22
4 ⅝”
22
11
/
16
”
3”
12
7
/
16
”
S2C SpeCiFiCationS anD DimenSionS
NOtE:
All EMI products are subject to ongoing development. Design and specifications may change without notice.
Circuit Designators: 9 = 9,000 Btuh • 2 = 12,000 Btuh
ex. - Model 9200 consists of one 9,000 Btuh compressor and one 12,000 Btuh compressor
Always refer to the rating plate for Minimum Circuit Ampacity on all multiple compressor units
