Grounding Instructions
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding
conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded
in accordance with all local codes and ordinances.
DANGER
Improper connection of an equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician
or service person if you are in doubt as to whether the outlet is properly grounded. Do not modify the plug provided with the
appliance. If it will not fit the outlet, have proper outlet installed by a qualified technician.
This appliance is for use on a nominal 120 volt circuit and has a grounding plug that looks like the plug illustrated in Figure
A. A temporary adapter which looks like the adapter illustrated in Figure B may be used to connect this plug to a two-pole
receptacle, as shown, if a properly grounded outlet is not available. The temporary adapter should be used only until a properly
grounded outlet, Figure A, can be installed by a qualified electrician. The green colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever the
adapter is used, it must be held in place by a metal screw.
NOTE: In Canada, the use of a temporary adapter is not permitted by the Canadian Electrical Code.
Figure A
Grounded Outlet Box
Grounding Blade
is Longest of the
Three Blades
Figure B
Grounded Outlet Box
Adapter
Grounding Tab
Metal Screw
3
Identify Parts Of Back Vac
Unpack accessories from carton and remove
vacuum cleaner.
Carpet Nozzle Wands
Lid
Tank
Dusting
Brush
Crevice Tool
Pigtail
Bare Floor Nozzle
5 ft. Hose
Power Switch
