ELAR 180 Pro RGBAW Data Sheet
2
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040 • Specifications subject to change without notice
www.ElationLighting.com • Toll Free (866) 245-6726
P h o t o m e t r i c s
ELAR 180 Pro RGBAW
Photometric Beam Angle Data
9° Beam Angle, 22° Field Angle / 10° Lens
LUX x 0.0929 = FC
22° Field Angle 9° Beam Angle
0 m
0 ft 2.5 m
8 ft
7.5 m
25 ft
5 m
16 ft
R (12)
G (12)
B (12)
W (12)
A (12)
Full (60)
108 FC / 1,166LUX
400 FC / 4,296 LUX
86 FC / 920 LUX
238 FC / 2,567 LUX
152 FC / 1,641 LUX
1,015 FC / 10,930 LUX
32 FC / 340 LUX
110 FC / 1,189 LUX
24 FC / 258 LUX
69 FC / 739 LUX
51 FC / 545 LUX
269 FC / 2,900 LUX
13 FC / 137 LUX
49 FC / 525 LUX
11 FC / 116 LUX
29 FC / 314 LUX
18 FC / 189 LUX
128 FC / 1,375 LUX
Ø 0.96 m / Ø 3.15 ft
Ø 0.39 m / Ø 1.28 ft
Ø 1.92 m / Ø 6.31 ft Ø 2.88 m / Ø 9.45 ft
Ø 0.78 m / Ø 2.56 ft Ø 1.17 m / Ø 3.84 ft
Beam Diameter
9° Beam Angle
22° Field Angle
