1 Description of Device
1
2
3
4
5
1. Moving Head
2. Carrying handles
3. LED- Display
4. Arm
5. Camlock system
M a x Min
DMX IN DMX OUT
Software Update
1.Ground 2.Data -
3.Data +
Mic Sensiti vity
6 7
8 9
10
15 6. Software-Update
connector
7. Microphone- Intensity
8. DMX- Input
9. DMX- Output
10. Fan (air inlet/outlet)
11. Power On/Off
12. Mains supply
(Powercon)
13. Fuse lamp
14. Fuse electronics
15. Carrying handles
Lamp Fuse Electronic Fuse
Power input:90 - 260V AC,
50 / 60Hz POWER
10
11 12
13 14 15
