A typical application using an MCS-1 for control
Audio
amplifier
IR out
Access
Port
MCS-1
RoHS
compliant
MADE IN AUSTRALIA
EIKI INDUSTRIAL CO., LTD
NANIWA BLDG.,
4-12 BANZAI-CHO, KITA-KU
OSAKA, 530-0028 JAPAN
1 - Gnd
2 - +12V
3 - Data
4 - IROut
5 - TxD 1
6 - RxD
7 - TxD 2
8 - PIR in
DC
I
n
9 -
1
2
v
+ -
ce
n
tre
RS232 ports
1-Pgm.
2-Aux.
MultiMedia
Port
Long <-
->
S
hor
t
PC
C
abl
e
C
o
m
pe
ns
at
ion
& power
Control
A out R
A out L
A in R
A in L
A in 2R
A in 2L
A in 1 V1in
V2in
V4in
Vout
RL1
RL2
+24v
Projector
PC
Relay
Mains
Desk
PC
DVD-VCR
combo
Video
RGBHV
External A/V
device, e.g.
camcorder
External PC,
e.g. laptop
RS-232
External
relay
connections
Connect the
coil of a 12v
UR approved
DIN rail relay
to “RL1” and
“+24v”.
The voltage
and current
limits are
determined by
the relay
used.
Rear
view
Front
view
