8
13. DEBRIS BAG - Collects shredded material.
14. BLOWER PIPES - Twist lock design.
15. PRIMER BULB - Pumping primer bulb before starting engine draws fresh fuel from the fuel tank, priming the
carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.
16. CHOKE - Choke is located on the side of the air cleaner. Move choke lever to "COLD START" ( ) to close choke
for cold starting. Move choke lever to "RUN" ( ) position to open choke.
S
PECIFICATIONS
MODEL ----------------------------------------------------- ES-210 Hand Held
Length ------------------------------------------------------- 330 mm (13.0 in.) (w/o vacuum attachment)
Width (w/rear handle) ------------------------------------- 285 mm (11.2 in.)
Height ------------------------------------------------------- 340 mm (13.4 in.)
Weight (dry) ------------------------------------------------ 4.1 kg (9.0 lb.) w/o blowerpipes)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Displacement ----------------------------------------------- 21.2 cc (1.39 cu. in.)
Bore ---------------------------------------------------------- 32.2 mm (1.27 in.)
Stroke -------------------------------------------------------- 26.0 mm (1.10 in.)
Carburetor -------------------------------------------------- Zama w/primer bulb
Ignition System -------------------------------------------- Flywheel Magneto, capacitor discharge ignition type
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Exhaust System -------------------------------------------- Spark Arrestor Muffler w / Catalyst
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50:1 two-stroke air cooled engine oil
Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil ------------------------------------------------------------ Power Blend TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.5 lit. (16.9 US fl. oz.)
Recoil Starter System -------------------------------------- Automatic Recoil Starter Centrifugal Type
Wide Open Throttle Speed (RPM) ----------------------- 7000 - 9000
Idle Speed (RPM) ------------------------------------------ 2400 - 3200
Maximum Air Volume -------------------------------------- 7.7 m 3 /min. (271 cu. ft./min.)
Maximum Air Speed w/pipes (MPH) -------------------- 65 m/sec (145 mph)
Sound Level at 50 ft. dB(A) scale per ANSI B 175.2 --- 71 dB(A)
