REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

INCLUDES ITEMS 2-4

CONTROL HANDLE KIT

1

17800352130

1

SCREW 5X35

1

90024205035

2

SCREW 5X25

1

90024205025

3

NUT 5

2

90050000005

4

INCLUDES ITEM 6

BAND ASY

1

30120029430

5

SCREW 5X14

1

90024205014

6

TRIGGER, THROTTLE

1

17801052130

7

CABLE, THROTTLE

1

V430000140

8

NUT 6

2

90050200006

9

COVER - CORRUGATED

1

V475000850

10

SPRING, THROTTLE RETURN

1

17804342230

11

LOCKOUT, THROTTLE

1

17801252730

12

LEVER, THROTTLE LOCKOUT

1

17809052632

13

SPRING, THROTTLE LOCKOUT

1

17801352630

14

INCLUDES ITEMS 16-18

IGNITION SWITCH ASY

1

A440000280

15

SCREW 3X10

1

9154503010

16

KNOB, SWITCH

1

16341049231

17

LABEL, SWITCH

1

89015712330

18

GRIP, HANDLE

1

35121352130

19

INCLUDES ITEMS 21-22

CLAMP KIT

1

61027252130

20

SCREW 5X28

1

90024205028

21

NUT 5

1

90050000005

22

99922204164

- 27 -

REVISED 10/21/08

Table of Contents

Part Number Index

PAS-260 Pro Attachment Series

Control Handle, Throttle Cable, Ignition Switch
