Connection Diagrams
Connecting a Preamp
Connection of a Preamp Level Device using XLR Inputs
This diagram shows the RPA-1 amplifier
connected to a preamplifier with XLR outputs.
This is the preferred method of connection
where possible.
Connection of a Preamp Level Device using RCA Inputs
This diagram shows the RPA-1 amplifier
connected to a preamplifier with RCA outputs.
If the preamplifier does not have XLR outputs,
this becomes the default connection.
