Emprex BPF-109D User Manual

User manual, Digital photo frame, Model: bpf-109d

MAIN UNIT
1. TFT display(screen)
2. Remote sensor
3. Power button
4. Play/Enter button
5. Return button
6. Navigation down button
7. Navigation up button
8. Navigation right button
9. Navigation left button
10. Mode button
11. Snooze/Alarm off button
12. Hanging hole
13. Speaker
14. Bracket
15. SD/MMC/XD/MS slot
16. USB port
17. DC jack
18. Phones jack
19. Hole

3
4

5
6

7
8
9

REMOTE CONTROL
1. Mode button
2. OSD button
3. Menu button
4. Navigation up button
5. Navigation left button
6. Enter button
7. F.BWD & previous button
8. Navigation down button
9. Volume+ button
10. Mute button
11. Power button
12. Play/pause button
13. Stop button
14. Navigation right button
15. F.FWD & next button
16. Volume- button

-ENGLISH 2-

DIGITAL PHOTO FRAME

USER MANUAL

Model: BPF-109D

Please read these instructions before you operate the unit

Manufacturer of this unit follows a principle of constant improvement and is not held responsible for any
changes that are made to the unit nor accepts any liabilities for these changes. Thanks for your choice of
our products.

Power supply

Phone jack

USB slot

SD/MMC/XD/MS

Snooze/Alarm off button

Play/pause button

Basic play


Plug one end of the AC adaptor into the DC input jack, then plug the other end into AC wall outlet.

For private listening, insert a headphone or earphone into the phone jack.
CAUTION: Listening at high power for a long moment could damage users' ears.

Insert a USB data traveller into the USB port to enjoy the audio files or pictures. When you need to unplug
the USB, please enter the main menu firstly, then unplug the USB data traveller.

Insert an SD/MMC/XD/MS card into the card slot to enjoy the audio files or pictures.

To sleep an extra several minutes when the alarm comes on, lightly touch the SNOOZE/ALARM OFF
button, the alarm will stop for several minutes and comes on again. Press and hold SNOOZE/ALARM OFF
button about 3 seconds in normal mode to disable the alarm function. (This button works as described
above only when the mode option is set to ALARM enabled.)

Press PLAY/PAUSE button to pause during playback, press this button again will resume playback.

Power on the unit then enter the main menu, the screen shows ten functions, eg: photo, music, photo &
music, movie, setup, calendar, clock, alarm, copy/delete and favorite.
Insert a USB data traveller or SD/MMC/XD/MS card first, press NAVIGATION BUTTON to select one of
the following function.

Press NAVIGATION buttons to select photo option, then press ENTER to confirm the selection. After the
player read it for several seconds, it begins to browse the picture automatically one by one. When photo in
auto play off mode, it enters Thumbnail mode directly.
During picture playing, press STOP button, thumbnail mode menu appears on the screen as below.
Thumbnail of each title: select the thumbnail by using NAVIGATION buttons and press ENTER to play.
Information: Resolution, created date, rotate, and slide show
Rotate: Highlight the rotate option and press ENTER to confirm, then enter the rotate mode, there are
three options appear in the bottom of the screen including Rotate it, Reset and return. Use NAVIGATION
buttons to select picture you desired to rotate, then press ENTER to rotate it. Select reset to restore the
picture. Select return to back the thumbnail mode.
