21
INSTALLATION
Positioning
Remove all the packaging and install the cooker
in a dry, ventilated room not near curtains, paper,
alcohol, petrol etc (See figure).
The appliance must be set on a heatproof
floor. The adjustable feet must not be
removed.
L.P.G. cookers or ovens MUST NOT be
installed below ground level, i.e. in a
basement, or aboard any boat, yacht or other
vessel.
This appliance is approved to class “1” regarding
overheating of surrounding surfaces.
It is mandatory to keep 20mm distance to the
adjacent furniture.
The cooking appliance must be fitted
with a stability chain firmly secured to the
wall (see fig).
Ventilation
The room containing the cooker should have an
air supply in accordance with B.S. 5440: Part 2:
Current Editions.
The following requirements for ventilation must
be met.
The cooker should not be installed in a bed
sitting room with a volume of less than 20m
3 , if it
is installed in a room of volume less 5m 3 an air
vent of effective area of 110cm 2 is required; if it is
installed in a room of volume between 5m 3 and
10m 3 , an air vent of effective area 50cm 2 is
required, while if the volume exceeds 11m 3 no air
vent is required. However, if the room has a door,
which opens directly to the outside, no air vent is
required even when the volume is between 5m
3
and 11m 3 .
If there are other fuel burning appliances in the
same room, B.S. 5440: Part. 2: Current Editions
should be consulted to determine the requisite air
vent requirements.
Location
The cooker may be located in a kitchen, a
kitchen/diner or bed sitting room but not in a
bathroom, shower room or garage.
For information regarding the fitting of flexible
supply pipes, the highest temperature at the rear
of this cooker which may come into contact with
the supply pipe is 70°C above ambient.
20mm 20mm
610 mm
690
mm
20mm 20mm
69
0 m
m
150 mm
Firmly fix
chain to rear
of cooker
Stability hook
Stability chain
Chain to be as short
as possible.
