Euro-Pro TRUE HEPA SHARK PLUS EP238 - Manual (Page 7)

Emptying the Cloth Dust Bag
• Hold the dust bag over a dustbin. Remove the clip by sliding it
off the dust bag sideways. (See fig. 9)
• Shake the contents of the dust bag into the dustbin..
• Close the dust bag by sliding the clip back onto the bottom edge
of the dust bag.
Please Note:
If you are using the cloth bag, you should wash the motor
protection filter (11) in lukewarm water once or twice a year.
Make sure that the filter is completely dry before you put it back
into the vacuum cleaner. (See fig. 10)
Fig. 10
Fig. 9
6
Cleaning the Deluxe Turbo Brush
Fig. 11
Flap Open
Attaching the Shoulder Strap
Use the hooks to attach the shoulder strap (21) to the vacuum cleaner.
First pass the flexible hose (12) through the loop of the shoulder strap (21)
and then attach the two hooks to the strap hookup holes (9) at the bottom
of the vacuum cleaner as shown in fig. 12.
To clean the deluxe turbo brush (23) of any obstructions,
open the flap located on the bottom of the deluxe turbo
brush (23) as shown in Fig. 11.
Fig.12
