34
Controlling the Projector Using RS-232C or Telnet
User Name Setting
([4]User Name)
Carrying out security protection using user name.
1
1
1
1
1 Enter “4” and press the “Enter” key.
2
2
2
2
2 Enter user name and press the “Enter” key.
Display set user name (*).
Note
• User name can be up to 8 characters.
• You can input the characters below :
a-z, A-Z, 0-9, -, _
• In the default state, user name is not set.
Password Setting
([5]Password)
Carrying out security protection using password.
1
1
1
1
1 Enter “5” and press the “Enter” key.
2
2
2
2
2 Enter password and press the “Enter” key.
Display set password (*).
Note
• Password can be up to 8 characters.
• You can input the characters below :
a-z, A-Z, 0-9, -, _
• In the default state, the password is not set.
setup>4
User Name
:
Please Enter
: EIP-4500
(change) —> EIP-4500
1
2
*
setup>5
Password
:
Please Enter
: eiki4500
(change) —> eiki4500
1
2
*
RS-232C Baud Rate Set-
ting
([6]RS-232C Baud Rate)
Setting of baud rate for RS-232C (COMPUTER and
PROJECTOR) terminals.
1
1
1
1
1 Enter “6” and press the “Enter” key.
2
2
2
2
2 Select and enter the number 0, 1 or 2 and
press the “Enter” key.
Display set baud rate (*).
Note
• Set the projector’s baud rate to the same rate as
that used by the computer.
Projector Name Setting
([7]Projector Name)
It is possible to assign a projector name.
1
1
1
1
1 Enter “7” and press the “Enter” key.
2
2
2
2
2 Enter projector name.
Display set projector name (*).
Note
• Projector name can be up to 12 characters.
• You can input the characters below :
A-Z, 0-9, -, _, (, ), space
(When “a-z” are input, they are converted to “A-Z”
automatically.)
• It is the same as the name which can be con-
firmed or set, using RS-232C commands “PJN0”,
“PJN1”, “PJN2” and “PJN3”.
setup>6
note: It sets both RS-232C (COMPUTER) and RS-232C (PROJECTOR).
0 ...
9600 bps
1 ... 38400 bps
2 ... 115200 bps
Baud Rate Select[0-2] :2
RS-232C Baud Rate : 115200 bps
1
2
*
setup>7
Projector Name
: EIP-4500
Please Enter
: MY EIP-4500
(change) —>
MY EIP-4500
1
2
*
