POWXG6011
Copyright © 2011 VARO P a g e | 7
Hints for mulch-mowing:
−
Regular cut-back by max .2 cm (for example from 6 cm to 4 cm grass heigh
−
Make sure the mowing blade is sharp
−
Do not mow wet grass
−
Set max. Motor speed
−
Move forward at low speed (allow mower to chopp grass in mower housing)
−
Regularly clean mulching wedge, housing inner side and mowing blade
6.2.1 Mounting mulching wedge
Make sure the motor stopped and blade has come to a complete
Fig.
5A
−
Lift the discharge flap and remove the grass collect box.
−
Push the mulching wedge into the discharge channel (Fig. 5A). Lock the mulching wedge
with housing (the nose on the bottom side of the mulching wedge grip must snap into the
opening in the housing (Fig. 5B)).
−
Lower the discharge flap again.
6.3 “3” convert to side-discharge mower
Make sure the motor stopped and blade has come to a complete
Fig. 6A Fig. 6B
Lift the discharge flap and remove the grass collect box.
Mount the mulching wedge (as described under To convert to mulching mower
Loosen the screw on the (6A) side wand flap and turn the flap to the side (6B)
EN
www.varo.com
cm grass height)
low speed (allow mower to chopp grass in mower housing)
wedge, housing inner side and mowing blade.
Make sure the motor stopped and blade has come to a complete standstill!!
Fig. 5B
). Lock the mulching wedge
mulching wedge grip must snap into the
Make sure the motor stopped and blade has come to a complete standstill!!
mulching mower).
flap and turn the flap to the side (6B).
