POWX353
EN
Copyright © 2014 VARO P a g e | 10 www.varo.com
 Remove and check the filter of dirt.
 If the filter is dirty, rinse in clean water and leave to air dry.
IMPORTANT
– Never operate the spray gun without the air filters in place.
Dirt could be sucked into the turbine and may interfere with the operation of
the spray gun.
WAARSCHUWING! Gebruik het toestel nooit zonder luchtfilter; er kan stof
naar binnen worden gezogen, wat de werking van de machine zou kunnen
verstoren.
9 TECHNICAL DETAILS
Model nr. POWX353
Voltage 230-240V
Frequency 50Hz
Power input 400W
Maximum nozzle flow rate 0-380gr/min
Container capacity 800ml
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
78 dB(A)
Acoustic power level LwA 89 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration) 3.9 m/s² K = 1.5 m/s²
11 TROUBLE SHOOTING
PROBLEM CAUSE SOLUTION
Motor hums but
does not spray or
irregular spraying. Pick up pipe not in the right
position
Blocked pick up pipe
Blocked nozzle
Blocked filter
Control knob needs adjustment Re-adjust pick up pipe.
Clean with thinner.
Clean nozzle.
Clean with thinner.
Adjust.
Atomization is not
good. Volume adjustment is not correct.
Paint too thick Adjust.
Check viscosity of the paint.
Over painting. Spray gun not clean, or not
lubricated resulting in piston being
stuck in cylinder
Too much paint
Viscosity too low Disassemble spray gun and clean
with thinner.
Adjust the volume clockwise to
reduce spraying. Two thin coats
are better then one
Check viscosity
Motor louder than
normal. Spray gun not clean, or not
lubricated, resulting in piston being
stuck in cylinder Disassemble spray gun and clean
with thinner.
