9 TECHNICAL DATA
POW67935
Max. pump capacity 3500 l/h
Max. lift 44m
Maximum suction level 7m
Max. water temperature 35°C
Min. diameter of pressure hose 3/4"
Min. diameter of suction hose < 5 m 1"
Min. diameter of suction hose > 5 m 1 1/4"
Mains voltage 230VAC/50HZ
Rated power 1000 Watt
Cable length 1.2 m
Inlet Pressure (working state) 1,5 bar
Outlet Pressure (working state) 3 bar
10 NOISE
Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA 71 dB(A)
Acoustic power level LwA 88 dB(A)
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
11 SERVICE DEPARTMENT
 Damaged switches must be replaced by our after-sales service department.
 If the connecting cable (or mains plug) is damaged, it must be replaced by a particular
connecting cable which is available from our service department. Replacement of the
connecting cable must only be carried out by our service department (see last page) or by
a qualified person (qualified electrician).
12 STORAGE
 Thoroughly clean the whole machine and its accessories.
 Store it out of the reach of children, in a stable and secure position, in a cool and dry
place, avoid too high and too low temperatures.
 Protect it from exposure to direct sunlight. Keep it in the dark, if possible.

Don’t keep it in plastic bags to avoid humidity build-up.
