Electrolux Blast Freezers
Blast Chiller/ Freezers - 7/15 kg
Internet: http://www.electrolux.com/foodservice
HDBA010
2007-05-02
RILSAN COATED GRID 881061 881061
PRINTER FOR HACCP BASIC VERSION 881532 881532 881532
PLASTIC COATED GRID-600X400 MM 880864 880864
PAIR OF 1/1 GN AISI 304 S/S GRIDS 921101 921101 921101
COOK&CHILL KIT-6 GN OVEN/15KG BL.CHILLER 881528 881528
4 WHEELS FOR BLAST CHILLERS 881097
4 FEET FOR UNDERCOUNTER BLAST CHILLER 881493
3-SENSOR PROBE FOR CHILLER+C/FREEZER 880088 880088 880088
2 SINGLE SENSOR PROBES CHILLER+C/FREEZER 880096 880096 880096
1 SINGLE SENSOR PROBE CHILLER+C/FREEZER 880089 880089 880089
*NOT TRANSLATED* 922166 922166 922166
*NOT TRANSLATED* 880269 880269
*NOT TRANSLATED* 880183 880183 880183
ACCESSORIES
1 SINGLE SENSOR PROBE CHILLER+C/FREEZER 1 1 1
INCLUDED ACCESSORIES
Net weight - kg. 95 95 105
installed-electric 0.831 0.14 1.51
Power - kW
at evaporation temperature - °C -23.3 -23.3 -25
Refrigerant power
Refrigeration power - W 814 1680 1072
Refrigerant quantity - g. 980 850
Refrigerant type R404a R404a R404a
N° defrost in 24 hrs. 6 6 6
Compressor power - HP 1
Max load capacity - trays h 65 mm - n° 3 3 3
Trays type GN 1/1; 600x400 GN 1/1; 600x400 GN 1/1; 600x400
Door hinges Right Side Right Side Right Side
N° and type of door 1 1 1
height 850 975 970
depth/with open doors 700, 1407 770, 1450 760, 1500
width 762 760 760
External dimensions - mm
Cooling unit Built-In Remote Built-In
Gross capacity (D.I.N. 8952) - l. 72 115 115
UK Guide lines 12.5, 7.2 19.5, 15.2 19.5, 15.2
NF Regulations 7.2, 5.4 10.8, 10.8 10.8, 10.8
Productivity per cycle - kg.
Type L - FREEZERS - 7 KG G - FREEZERS - 15 KG G - FREEZERS - 15 KG
TECHNICAL DATA
RBF051
726659
RBF061R
726628
RBF061
726627
• Door equipped with removable
magnetic gasket with hygienic
design.
• Door handles entirely in pressed
stainless steel with no joints
gathering dust and dirt.
• All motors and fan waterproof
protected IPX44.
• Evaporator with anti rust
protection.
• Ventilator (fan) swinging hinged
panel for access to the evaporator
for cleaning.
• Automatic heated door frame.
• Hot gas defrosting system.
• Solenoid valve.
• 1 thermostatic expansion valve.
• High legs 150 mm with height
adjustment of -15/+80 mm (except
the undercounter models).
• Stand alone printer as optional,
built in on request.
• PC connection as standard, gate
RS 485.
• Removable container guide
runners.
INSTALLATION
• No water connections required.
• Waste can be plumbed into
drain, but can also be collected in
optional waste container.
*NF HYGIENE ALIMENTAIRE
certifying authority : AFAQ AFNOR
CERTIFICATION. Adress:11, Avenue
Francis de Pressense - 93571
Saint-Denis La Plaine Cedex - France.
Conformity with regulation NF031.
Certified guarantees: fitness for cleaning,
thermal performance
