3-20
E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
AUTO ADJUST
Adjusts the shape of the screen automatically at the full screen pattern.
LANGUAGE
Select the language in which adjustment menus are displayed. The following
languages are available: English, French, German, Italian, Spanish and
Japanese.
H/VPOSITION
H-POSITION
H-Position adjusts the horizontal position of the entire screen.
V-POSITION
V-Position adjusts the vertical position of the entire screen.
CLOCK PHASE
PHASE
Adjusts the noise of the screen image.
CLOCK
Adjusts the horizontal size of the entire screen image.
