Electrolux Dishwashing

Rack Type WTM140

Internet: http://www.electrolux.com/foodservice

IEBA010

2012-07-26

Subject to change without notice

STEAM DRYING TUNNEL-MODULAR RT-R>L-900

864514

STEAM DRYING TUNNEL-MODULAR RT-L>R-900

864515

SPLASH HOOD-MODULAR RACK T.-LOADING SIDE

865177

865177

865177

865177

865177

865177

KIT SILASTIC CURTAINS FOR RACK TYPE DW

864245

864245

864245

864245

864245

864245

KIT 9 BASKETS FOR 1-TANK RACK TYPE DW

867051

867051

867051

867051

867051

867051

KIT 6 BASKETS FOR 1-TANK RACK TYPE DW

867050

867050

867050

867050

867050

867050

EL. DRYING TUNNEL-EL.MODULAR RT-R>L-900

864500

864500

EL. DRYING TUNNEL-EL.MODULAR RT-R>L-600

864510

864510

EL. DRYING TUNNEL-EL.MODULAR RT-L>R-900

864501

864501

EL. DRYING TUNNEL-EL.MODULAR RT-L>R-600

864511

864511

EL. DRYING TUNNEL-CORNER-LEFT-MODULAR RT

864513

864513

EL. DRY. TUNNEL-CORNER-RIGHT-MODULAR RT

864512

864512

DRAIN KIT FOR MODULAR+COMPACT RACK TYPE

864150

864150

864150

864150

864150

864150

BASKET FOR 5 HALF INSULATED TRAYS-RED

867005

867005

867005

867005

867005

867005

12 S/S PLUGS FOR WASH.ARMS-MODUL/COMP.RT

864239

864239

864239

864239

864239

864239

ACCESSORIES

Total installed power - kW

27.4

27.4

27.4

27.4

6.4

6.4

Steam consumption peak - Kg/h

92

92

relative dynamic pressure bar - min/max

1.5, 3

1.5, 3

Steam supply

water flow - liters/hr

240

240

240

240

240

240

boiler power - kW

12

12

12

12

boiler capacity - lt.

12

12

12

12

12

12

temperature - °C

84

84

84

84

84

84

Rinsing

pump power - kW

0.35

0.35

0.35

0.35

0.35

0.35

tank capacity - lt.

23

23

23

23

23

23

temperature - °C

60-70

60-70

60-70

60-70

60-70

60-70

Duo rinse

pump power - kW

2.2

2.2

2.2

2.2

2.2

2.2

tank capacity - lt.

100

100

100

100

100

100

temperature - °C

55-65

55-65

55-65

55-65

55-65

55-65

1st wash

height/with open door

1771, 2119

1771, 2119

1771, 2119

1771, 2119

1771, 2119

1771, 2119

depth

884

884

884

884

884

884

width

1773

1773

1773

1773

1773

1773

External dimensions - mm

Insulation

Air emission - m³/h

180

180

180

180

Capacity baskets/h 1st/2nd speed

140, 80

140, 80

140, 80

140, 80

140, 80

140, 80

Capacity dishes/h 1st/2nd speed

2520, 1440

2520, 1440

2520, 1440

2520, 1440

2520, 1440

2520, 1440

cold water inlet °C

15

15

15

15

hot water inlet °C

50

50

50

50

50

50

pressure min. , max. - bar

1.5, 7

1.5, 7

1.5, 7

1.5, 7

1.5, 7

1.5, 7

Water supply

Energy Saving Device incl. cond. unit

Feeding direction

from RH to LH

from LH to RH

from RH to LH

from LH to RH

from RH to LH

from LH to RH

Power supply

Electric

Electric

Electric

Electric

Steam & Electric

Steam & Electric

Model

Electronic - A

Electronic - A

Electronic - B

Electronic - B

Electronic - A

Electronic - A

TECHNICAL DATA

WTM140ERA

534100

WTM140ELA

534101

WTM140ERB

534102

WTM140ELB

534103

WTM140SRA

534124

WTM140SLA

534125

• Wash arms and double tank filter
(flat and deep box) easy to remove.
• Height adjustable stainless steel
feet.
• All models finished in top quality
materials with double skinned
construction to aid durability and
reduce noise.
• Self-draining wash pumps
provide maximum hygiene.
• Hinged flap for easy access to
the energy saving condenser unit.
• Large balanced inspection doors
for easy access to wash area.
• Self-cleaning cycle in washing
and rinse zones.

EASY TO USE
• Automatic start/stop function.
• Advanced electric control panel
with sound signals and visual
display.
• Counter balanced door with
safety switch and easy to grip
handle.
• Built-in rinse water heater to
increase the temperature of the
final rinse water.
• Electronic control panel with
autodiagnostic check control.

EASY ON THE ENVIRONMENT
• 35mm thickness foam injection
insulated doors to reduce noise
and reduce heat dispersion.
• Available with version equipped
with Energy Saving Device (ESD)
to pre-heat the incoming cold
water and to save up to 12kW of
energy. ESD incorporates a
condenser unit to decrease
temperature and humidity of the
outlet hot steam.
• 98% recyclable by weight.
• CFC free packaging.
• Low noise level <70dBA.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
