BEWARE OF ELECTRIC SHOCK!
Leaks can put your life at risk from
electric shocks. Carefully check that
all connections are watertight. Also ensure that
all wires of electric appliances are correct and
have been securely installed.
Any leakage or sudden escape of water can
cause considerable damage to buildings and
property. All connections must therefore be
checked carefully to ensure that they are tight.
Familiarise yourself prior to installation with all
local conditions, e.g. water connections and
shut-off device.
Assembly
Installing the fitting
1. Shut off the main water supply. Allow
the remaining water to run off.
2. Screw the threaded sleeve with the short thread
12 into the ring nut 16 .
3. Guide the two hose tails 15 through the threaded
sleeve 12 .
4. Screw the two hose tails 15 hand-tight into the
connections 21 a , 21 b provided for them on the
underside of the tap (Fig. B). The two hoses are
identical and suitable for either hot or cold water.
5. Place the sealing ring 9 into the groove on
the underside of the ring nut 16 .
6. Insert the hose tails 15 and the threaded sleeves
12 through the opening in the draining board.
7. Push the seal 10 and the metal washer 11
from below over the threaded sleeve 12 .
8. Screw the ring nut 13 on to the threaded
sleeve 12 so that the tap can be fastened to
the draining board. When doing this take into
account the space required to swing the tap
from one side to the other.
9. Tighten the locking screws 14 using a Philips
screwdriver to further fix the ring nut 13 in place.
10. Connect the hose tails 15 to the water connec-
tion pipes.
CAUTION:
Do not twist the hoses or place them under
tension.
Check all connections carefully after first-time
installation to make sure that they are tight.
In the event of incorrect installation, all waranty
claims – particularly in relation to subsequent
damage – are excluded.
Use
Bringing into use
Note: If the tap has not been used for a long period
flush the pipes through thoroughly in order to avoid
stagnation and build-up of residues.
1. Open the water supply stopcocks.
2. Pull the lever
2 in the direction of the arrow
and swivel it to the right or left to regulate
the strength or temperature of the water flow.
3. Press the changeover button 1 on the spray
head to change from water jet to spray jet. This
function is helpful when cleaning vegetables
and fruit as they could be damaged by normal
water jets. Press the changeover button
1 on
the spray head again to return to a normal
water jet.
4. Push the lever 2 in the direction of the arrow
to stop the flow of water.
Hot water: Turn the lever 2 to the right.
Cold water: Turn the lever 2 to the left.
Check operation of the mixer. To do so, swing
the lever 2 into all permissible positions.
Please check the connections regularly to
ensure that they are tight.
Pull the spray head down slightly and then
forward out of the holder to have freedom of
movement of the spray head when in use.
