Electrolux Dishwashing
Rack Type WTM200
Internet: http://www.electrolux.com/foodservice
IEBD010
2012-07-26
Subject to change without notice
Net weight - kg. 602 602 560 560 602 602
Total installed power - kW 31.8 31.8 31.8 31.8 7.7 7.7
Steam consumption peak - Kg/h 92 92
relative dynamic pressure bar - min/max 1.5, 3 1.5, 3
Steam supply
water flow - liters/hr 300 300 300 300 300 300
boiler power - kW 16.5 16.5 16.5 16.5
boiler capacity - lt. 12 12 12 12 12 12
temperature - °C 84 84 84 84 84 84
Rinsing
pump power - kW 0.35 0.35 0.35 0.35 0.35 0.35
tank capacity - lt. 23 23 23 23 23 23
temperature - °C 60-70 60-70 60-70 60-70 60-70 60-70
Duo rinse
pump power - kW 3.3 3.3 3.3 3.3 3.3 3.3
tank capacity - lt. 150 150 150 150 150 150
temperature - °C 55-65 55-65 55-65 55-65 55-65 55-65
1st wash
pump power - kW 0.23 0.23 0.23 0.23 0.23 0.23
tank capacity - lt. 45 45 45 45 45 45
temperature - °C <35 <35 <35 <35 <35 <35
Pre-wash
height/with open door 1771, 2119 1771, 2119 1771, 2119 1771, 2119 1771, 2119 1771, 2119
depth 884 884 884 884 884 884
width 2852 2852 2852 2852 2852 2852
External dimensions - mm
Insulation ● ● ● ● ● ●
Air emission - m³/h 180 180 180 180
Capacity baskets/h 1st/2nd speed 200, 130 200, 130 200, 130 200, 130 200, 130 200, 130
Capacity dishes/h 1st/2nd speed 3600, 2340 3600, 2340 3600, 2340 3600, 2340 3600, 2340 3600, 2340
cold water inlet °C 15 15 15 15 15 15
hot water inlet °C 50 50 50 50 50 50
pressure min. , max. - bar 1.5, 7 1.5, 7 1.5, 7 1.5, 7 1.5, 7 1.5, 7
Water supply
Energy Saving Device incl. cond. unit ● ● ● ●
Feeding direction from RH to LH from LH to RH from RH to LH from LH to RH from RH to LH from LH to RH
Power supply Electric Electric Electric Electric Steam & Electric Steam & Electric
Model Electronic - A Electronic - A Electronic - B Electronic - B Electronic - A Electronic - A
TECHNICAL DATA
WTM200ERA
534108
WTM200ELA
534109
WTM200ERB
534110
WTM200ELB
534111
WTM200SRA
534130
WTM200SLA
534131
• As optional extra the WTM200
can be equipped with a drying
zone for fast and efficient drying.
EASY TO CLEAN AND MAINTAIN
• The pre-wash, wash and rinse
tanks are pressed with completely
rounded corners and sloping base
to facilitate cleaning.
• WTM200 has smooth surfaces.
304 AISI stainless steel front and
side panels, strainers and wash
and rinse arms.
• Wash arms and double tank filter
(flat and deep box) easy to remove.
• Height adjustable stainless steel
feet.
• All models finished in top quality
materials with double skinned
construction to aid durability and
reduce noise.
• Self-draining wash pumps
provide maximum hygiene.
• Hinged flap for easy access to
the energy saving condenser unit.
• Large balanced inspection doors
for easy access to wash area.
• Self-cleaning cycle in pre-wash,
wash and rinse zones.
EASY TO USE
• Automatic start/stop function. • Advanced electric control panel
with sound signals and visual
display.
• Counter balanced door with
safety switch and easy to grip
handle.
• Built-in rinse water heater to
increase the temperature of the
final rinse water.
• Electronic control panel with
autodiagnostic check control.
EASY ON THE ENVIRONMENT
• 35mm thickness foam injection
insulated doors to reduce noise
and reduce heat dispersion.
• Available with version equipped
with Energy Saving Device (ESD)
to pre-heat the incoming cold
water and to save up to 12kW of
energy. ESD incorporates a
condenser unit to decrease
temperature and humidity of the
outlet hot steam.
• Separate pre-wash, wash and
rinse tanks for lower water and
detergent consumption. No
overflow of the detergent from the
wash tank to the others and no
need for fresh water in order to
cool down the water in pre-wash
tank. • 98% recyclable by weight.
• CFC free packaging.
• Low noise level <70dBA.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
