Echo PAS-261 User Manual
Page 3
3
ITEM
PART NUMBER QTY DESCRIPTION
REMARKS
PAS-260, 261
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
OPTIONAL ENGINE REPOWER
SB1047
1
SHORT BLOCK
INCLUDES ITEMS 2-18
A130000122
1
CYLINDER
90016205022
4
BOLT 5X22
V100000010
1
GASKET, CYLINDER
P021002360
1
PISTON KIT
INCLUDES ITEMS 6-9
A101000010
2
RING, PISTON
V606000000
1
PIN, PISTON
10001504630
2
CIRCLIP, PISTON PIN
10001455930
2
SPACER, PISTON PIN
V553000020
1
BEARING, NEEDLE
A011000030
1
CRANKSHAFT ASY
P021000940
1
CRANKCASE KIT
INCLUDES ITEMS 13-18
10021305530
1
OIL SEAL
90080036001
2
BEARING, BALL 6001
90070200028
1
CIRCLIP 28
10024255930
1
GASKET, CRANKCASE
90016205025
4
BOLT 5X25
10021228230
1
OIL SEAL
A160000040
1
COVER, CYLINDER
9111005016
1
BOLT 5X16
V353000020
1
COLLAR 5
A162000000
1
GUARD, TOP
90024205010
1
SCREW 5X10
16201452930
1
LEAD, GROUND
A411000010
1
COIL, IGNITION
90016205016
2
BOLT 5X16
15611240630
1
GROMMET
15901203433
1
CAP, SPARK PLUG
15901103432
1
TERMINAL, SPARK PLUG CAP
99944500071
1
SPARK PLUG -- BPM-7Y
15901010230
1
SPARK PLUG -- BPMR-7A
CANADA MODELS: 04001001-04999999
16201056430
1
LEAD, GROUND
A409000020
1
FLYWHEEL
90051500008
1
FLANGE NUT 8
MODELS PAS-260 SERIAL NUMBERS: 03001001-04999999
P021002351
1
GASKET KIT
MODELS PAS-261 SERIAL NUMBERS: 02001001-02999999
P021001521
1
GASKET KIT
SERIAL NUMBERS: 02001001-04999999
ENGINE, SHORT BLOCK, IGNITION, CYLINDER COVER
Also Included In GASKET KIT
