EVO FX2 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
7
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
59 20 x 40mm Washer 1 FX2-59 89 10mm Washer 2 FX2-89
60 M16 Nut 1 FX2-60 90 6mm Washer 2 FX2-90
61 M10 x 67mm Bolt 1 FX2-61 91 (Pre-Assembled) FX2-91
62 M10 Nut 5 FX2-62 92 16mm Washer 2 FX2-92
63 Bumper 1 FX2-63 93 M8 Nut 3 FX2-93
64 Deck Rear End Cap Screw 4 FX2-64 94
Handlebar Front End Cap
Left-2
1 FX2-94
65 Metal Plate 2 FX2-65 95
Handlebar Front End Cap
Right-1
1 FX2-95
66 Rear Roller Washer 2 FX2-66 96
Handlebar Front End Cap
Left-1
1 FX2-96
67 Rear Roller Bolt 2 FX2-67 97
Handlebar Front End Cap
Right-2
1 FX2-97
68 Power Switch Board 1 FX2-68 98 M8 x 36mm Bolt 2 FX2-98
69 Foot Up Lock 1 FX2-69 99 M4 x 15mm Screw 3 FX2-99
70 Caster Holder 2 FX2-70 100 Console Bar End Cap 2 FX2-100
71 Base Frame End Cap 2 FX2-71 101
Console Support Locating
Screw
1 FX2-101
72 Base Frame Rubber Cushion 2 FX2-72
73 8mm Washer 10 FX2-73
74 (Pre-Assembled) FX2-74
75 M10 x 58mm Bolt 4 FX2-75
76 M10 x 26mm Bolt 2 FX2-76
77 M8 x 18mm Bolt 6 FX2-77
78 (Pre-Assembled) FX2-78
79 M4 x 12mm Screw 8 FX2-79
80 Plastic Cover 2 FX2-80
81 M6 x 15mm Bolt 2 FX2-81
82 M10 x 20mm Bolt 4 FX2-82
83 M10 x 26mm Bolt 2 FX2-83
84 M8 x 45mm Bolt 2 FX2-84
85 M16 x 73mm Bolt 2 FX2-85
86 (Pre-Assembled) FX2-86
87 M3.5 x 16mm Screw 4 FX2-87
88 Console Screw 2 FX2-88
