22
S
PECIFICATIONS
MODEL ----------------------------------------------------- PAS-230
Unit Length ------------------------------------------------- 1025 mm (40.4 in.)
Width -------------------------------------------------------- 250 mm (9.84 in.)
Height ------------------------------------------------------- 250 mm (9.84 in.)
Weight (dry) ------------------------------------------------ 4.0 kg (8.82 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 32.2 mm (1.27 in.)
Stroke -------------------------------------------------------- 28.0 mm (1.10 in.)
Displacement ----------------------------------------------- 22.8 cc (1.39 cu. in.)
Exhaust ------------------------------------------------------ Spark Arrestor Muffler with catalyst
Carburetor -------------------------------------------------- Zama w/purge pump
Ignition System -------------------------------------------- CDI (capacitor discharge ignition)
Spark Plug -------------------------------------------------- NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ----------------------------------------------- 50:1 two-stroke air cooled engine oil
Gasoline ----------------------------------------------------- 89 Octane unleaded. DO NOT use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE.
Oil ------------------------------------------------------------ Power Blend TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity ---------------------------------------- 0.58 lit. (19.6 US fl. oz.)
Starter System ---------------------------------------------- Automatic Rewind Starter
Clutch ------------------------------------------------------- Centrifugal Type
Drive Shaft -------------------------------------------------- 6.35 mm (1/4 in.) flexible shaft
Idle Speed --------------------------------------------------- 2,750 - 3,250
Wide Open Throttle Speed (W.O.T.) RPM ------------- 8,500 - 10,500
ECHO APPROVED OPTIONAL ATTACHMENTS
WARNING DANGER
• Use only ECHO approved attachments for Pro Attachment Series TM models. Serious injury may result from the use
of non-approved attachment combinations. Read and comply with all safety instructions listed in this manual and
in the attachment manual.
RECOMMENDED OPTIONAL ATTACHMENTS
• PAS Edger Model 99944200470
• PAS Cultivator Model 99944200510
• PAS Trimmer Model 99944200540
• PAS Hedge Clipper Model 99944200480
• PAS Power Pruner TM Model 99944200530
• PAS Pro Sweep TM Model 99944200550
• PAS Pro Thatch TM Model 99944200560
• PAS Articulating Hedge Clipper Model 99944200590
• PAS Rapid Loader TM Model 99944200610
• PAS Brush Cutter Model 99944200600
• PAS ProPaddle Model 99944200620
NOTE
ECHO, INC. will not be responsible for the failure of cutting devices, attachments, or accessories which have not been
tested and approved by ECHO for use with this Pro Attachment Series
TM unit.
