C-37
Touchmonitor Specifications ET1549L
Table C.2 15" LCD Touchmonitor Specifications
Display Type
Active matrix, thin film transistor
(TFT), liquid crystal display
Size
15-inch diagonal
308 x 232 mm useful screen area
Pixel Format 1024 x 768
Touchscreen
0.125-inch IntelliTouch
Surface wave technology
Colors 262,144
Display
Brightness IntelliTouch: 225 cd/m² Max.
Back-light Lamp
Life 50,000 hours at full brightness
typical
Viewing Angle
Horizontal
Vertical
±80 or 160 degrees total
±80 or 160 degrees total
Contrast Ratio 400:1 typical
Display Response
Time 15 ms(tr)/10 ms(TF)
Environmental
Operating Temp
Storage Temp
Humidity
0°C to 50°C
-30°C to +60°C
80% non-condensing
Mechanical
Weight
Size
10.6 lbs. maximum approx.
weight for IntelliTouch and
SecureTouch
See drawings on pages 41.
Electrical
Input Video
Input Power
Power Dissipation
VGA/SVGA/XGA analog video
100-240 VAC, 50/60 Hz.
Universal
Agencies
Safety & EMC UL, cUL and TUV
FCC-B, CE, C-Tick, MRPII and
VCCI
