Removing the lcd panel – eMachines G630 User Manual
Page 88
78
Chapter 3
Removing the LCD Panel
1. See “Removing the Camera Module” on page 77.
2. Remove the two (2) securing screws from the LCD Panel.
3. Remove the adhesive strip holding the cables in place.
4. Remove the Camera cable cluster from the LCD Module as shown.
Step
Size
Quantity
Screw Type
LCD Panel
M2.5*6
2
