44 PHKSA 18-Li A1
GB
MT
Introduction
Congratulations on the purchase of your
new appliance. You have selected a high
quality product. The operating instructions
are part of this product. They contain
important information on safety, usage
and disposal. Before using the product,
familiarise yourself with all handling and safety
instructions. Use the product only as described and
for the range of applications specifi ed. Hand over
all documents when the product is passed on to a
third party.
Intended use
This hand-held circular saw (hereinafter "appliance")
is designed for longitudinal, cross and mitre cuts in
fi rmly supported solid wood, chip board, plastics
and lightweight construction materials. Any other
usage of or modifi cation to the appliance is deemed
to be improper and carries the risk of serious
personal injury. Not for commercial use.
Features
Figure A:
Safety lock-out
ON/OFF switch
Cutting depth scale
Release button for battery pack
Battery charge level button/battery display LED
Battery pack
Locking screw
Spindle lock
Base plate
Rip fence slot
Figure B:
ON/OFF/RESET switch laser
Auxiliary handle
Laser warning label
Laser exit opening
Cutting angle scale
Wing screw for cutting angle preselector
Wing screw for rip fence slot
Rip fence
Blade guard
Clamping fl ange
Clamping screw
Release lever for the blade guard
Saw blade
Chip ejector
Vacuum adapter for dust extraction
Allen key
Figure C:
Charger
Red control LED
Green control LED
Package contents
1 cordless circular saw
1 rapid battery charger
1 rip fence
1 vacuum adapter for dust extraction
1 SW 6 Allen key
1 saw blade (pre-assembled)
Operating instructions
Technical data
Cordless circular saw: PHKSA 18-Li A1
Rated voltage:
18 V
Idle speed: n
0
= 3800 min -1
Saw blade: 1x Ø 150 mm x Ø 16 mm,
18 teeth
Max. cutting depth: 90°: 48 mm
45°: 36 mm
Battery: PAP 18 A1
Type:
LITHIUM ION
Rated voltage: 18 V
Capacity: 1.5 Ah
Rapid battery charger: PLG 18 A1
INPUT:
Rated voltage:
230 - 240 V ~, 50 Hz
Power consumption: 40 W
OUTPUT:
Rated voltage:
18 V
Charging current: 1.8 A
Charging time: approx. 60 min
Fuse (internal): 2 A T2A
Protection class: II /
