34 GB
Introduction
Plunge saw PTS 500 A1
Introduction
Congratulations on your purchase. You have selected
a high quality product. The instructions for use are
a part of this product. They contain important infor-
mation about safety, use and disposal. Before using
the product, please familiarise yourself with all the
operating and safety instructions. Use the product
only as described and for the specified applications.
When passing this product on to others please be
sure to also include all of its documentation.
Intended use
The machine is primarily intended for lengthwise
and across cuts in plunge cut with solid support in
solid wood, chipboard, plywood, aluminium, tiles,
stone, plastic and lightweight construction materials.
Please keep in mind that the pre-fitted saw blade is
only suitable for cutting wood. Any other uses, and /
or modifications to the appliance, are deemed to be
improper usage and may result in serious physical
injury. Not for commercial applications.
Features
1 Mechanical plunge blocker
2 Power On / Control LED
3 Mains lead
4 Ventilation slits
5 Cover for brushes
6 ON /OFF switch
7 Pre-selector for cutting depth
7 a Scale for cutting depth
8 Labelling cutting length
9 Base plate
10 Uptake parallel fence
11 Parallel fence
11 a Screw for parallel fence
12 Window for cutting line
13 Spindle lock
14 Connection for dust extraction
15 Allen key
16 Saw blade
17 Clamping flange
18 Clamping screw and washer
19 Dust extractor hose
20 HW-Circular saw blade Z85 / 30
21 Diamond cutting disc Z85VR
22 HS Circular saw blade Z85 / 36
Scope of delivery
1 Plunge saw PTS 500 A1
1 HW Circular saw blade Z85 / 30
1 Diamond cutting disc Z85VR
1 HS Circular saw blade Z85 / 36
1 Parallel fence
1 Dust extractor hose
1 Allen key
1 Carry case
1 Set of operating instructions
Technical Data
Rated power: 500 W
Rated voltage: 230 V∼, 50 Hz
Idling speed: n
0
4500 min -1
Max. cutting depth: 25 mm
Protection class:
II /
Noise and vibration data:
Measurement for noise level, determined according
to EN 60745. The A-rated noise levels of the elec-
trical power tool are typically at:
Sound pressure level: 82 dB(A)
Sound power level:
93 dB(A)
Uncertainty K: 3 dB
Wear hearing protection!
Evaluated acceleration, typically:
Hand / arm vibration a
h
= 2.266 m / s 2
Uncertainty K = 1.5 m / s 2
The vibration level given in these
operating instructions has been measured in a pro-
cedure according to EN 60745 and can be used
for the comparison of appliances. The vibration
Introduction / General power tool safety warnings
