42 GB
The planer blade 20 has two cutting edges and it
can be fitted either way around.
Replace the planer blade 20 when both cutting
edges are blunt.
Do not resharpen the planer blades 20 .
Reversing or replacing a planer blade 20
IMPORTANT INFORMATION:
Do not release the two Allen keys. They are used to
adjust the height of the blade shaft.
Adjustment is necessary only if you wish to use a
different planer blade type e.g. a profiled blade.
Always replace both blades at the same time to
avoid out of balance forces.
NOTE: If you only release one blade first then you
can use the factory-fitted second blade for orientation
when you fit the new blade.
1. Release the 3 bolts of the cutting element
18
using the supplied open spanner 26 .
Press the removable side guard 21 into the slot
in the housing.
2. Push the cutting element 18 sideways out from
the blade shaft 17 .
3. Push the planer blade 20 sideways out from
the cutting element 18 .
4. Reassembly is carried out in the reverse order
with a reversed or new planer blade.
5. Planer blades 20 can be obtained from the
service address indicated (see section about
warranty).
Q
Replacing a drive belt
(see Figs. F + G)
DANGER OF INJURY!
Before you carry out any work on the device always
pull the mains plug out of the mains socket.
Release the screws 5 and remove the belt
cover 4 .
Remove the worn drive belt 23 .
First place the new drive belt 23 on to the small
belt wheel 25 and then pull the drive belt 23
on to the large belt wheel 24 by rotating it.
Put the belt cover 4 back into position and
fasten it into place with the screws 5 .
Q
Maintenance and cleaning
DANGER OF INJURY!
Before you carry out any work on the device always
pull the mains plug out of the mains socket.
Always keep the device and the ventilation
slots clean. This way you will work more safely
and produce better results.
Clean out the planing debris removal port 3
regularly.
Clean out a blocked planing debris removal
port using suitable means (e.g. piece of wood,
air under pressure, etc.).
Use a dry cloth to clean the housing.
Remove any adhering planing dust with a
narrow paint brush.
In no circumstances use sharp objects, or petrol,
solvents or cleaning agents that might attack
plastic. Do not allow any liquids to enter the
inside of the device.
Q
Service centre
Have your device repaired
only by qualified specialist personnel
using original manufacturer parts only.
This will ensure that your device remains safe
to use.
If the plug or mains lead
needs to be replaced, always have
the replacement carried out by the
manufacturer or its service centre. This
will ensure that your device remains safe to use.
Q
Warranty
The warranty for this appliance is for 3 years
from the date of purchase. The appliance
has been manufactured with care and me-
ticulously examined before delivery. Please
retain your receipt as proof of purchase. In
Preparing for use / Maintenance and cleaning / Service centre / Warranty Warranty / Disposal
