7.2 Torque setting (Fig. 4 / Item 1)
The cordless screwdriver is fi tted with a mechani-
cal torque selector.
The torque for a specifi c size of screw is selected
with the set-collar (1). The correct torque depends
on several factors:
•
on the type and hardness of material in ques-
tion
•
on the type and length screws used
•
on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to in-
dicate when the set torque is reached.
Important! The tool must be at a standstill
when you set the torque with the setting
ring.
7.3 Drilling (Fig. 4 / Item 1)
For drilling purposes, move the set-collar to the
last step „Drill“. In this setting the slip clutch is in-
active. The maximum torque is available in drilling
mode.
7.4 Selecting 1st gear to 2nd gear
(Fig. 4/Item 2)
By adjusting the selector switch, you can work
with a faster or slower turning speed. Change
the gear only when the drill is at a standstill. If
you fail to observe this point, the gearing may be
damaged.
7.5 Battery capacity indicator
(Fig. 4/Item. 3)
Press the button for the battery capacity indicator
(a). The battery capacity indicator (3) indicates
the charge state of the battery on 3 coloured
LEDs.
7.6 Forward/Reverse switch
(Fig. 5 / Item 4)
With the slide switch above the On/Off switch
you can select the direction of rotation of the
battery-powered drill/screwdriver and secure it
against being switched on accidentally. You can
choose between clockwise and anticlockwise
rotation. To avoid causing damage to the gearing
it is advisable to change the direction of rotation
only when the tool is at a standstill. The On/Off
switch is blocked when the slide switch is in centre
position.
7.7 On/Off switch (Fig. 5 / Item 7)
Infi nitely variable speed control is possible with
the On/Off switch. The further you press the
switch, the higher the speed of the battery-powe-
red drill/screwdriver.
7.8 LED lamp (Fig. 5/Item 8)
The LED lamp (8) can be used in poor lighting
conditions to illuminate the area where you want
to drill or screw. The LED lamp (8) will be lit au-
tomatically as soon as you press the ON/OFF
switch (7).
7.9 Changing the tool (Fig. 6)
Important. Set the changeover switch (4) to its
centre position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the cordless screwdriver.
•
The cordless screwdriver is fitted with a quick-
action chuck (10) with an automatic spindle
stop.
•
Open the chuck (10). The chuck opening (b)
must be large enough to hold the tool (drill bit
or screwdriver bit).
•
Select the suitable tool. Push the tool as far as
possible into the chuck opening (b).
•
Tighten the chuck (10) and then check that the
tool is secure.
7.10 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as de-
scribed elsewhere in these operating instructions,
to suit the size of screw.
7.11 Integrated magnetic bit mount
(Fig. 7-8)
The cordless drill/screwdriver has an integrated
magnetic bit mount (9) for 1/4-inch (6.35mm) bit
inserts.
