more than one rotation.
•
Now, using a little more force, slacken the
flange bolt (31) in the clockwise direction.
•
Turn the flange screw (31) right out and remo-
ve the external flange (32).
•
Take the blade (7) off the inner flange (38)
and pull out downwards.
•
Carefully clean the flange screw (31), outer
flange (32) and inner flange (38).
•
Fit and fasten the new saw blade (7) in rever-
se order.
•
Important! The cutting angle of the teeth,
in other words the direction of rotation of the
saw blade (7) must coincide with the direction
of the arrow on the housing.
•
Before continuing your work make sure that
all safety devices are in good working condi-
tion.
•
Important! Every time that you change the
saw blade (7), check to see that it spins freely
in the table insert (11) in both perpendicular
and 45° angle settings.
•
Important! The work to change and align
the saw blade (7) must be carried out correct-
ly.
7.8 Transport (Fig. 1-3)
•
Retighten the locking grip (13) to secure the
turntable (16) in place.
•
Activate the release lever (3), press the ma-
chine head (5) downwards and secure with
the safety pin (25). The saw is now locked in
its bottom position.
•
Fix the saw’s drag function with the locking
screw for drag guide (24) in rear position.
•
Carry the equipment by the fixed saw table
(17).
•
When reassembling the equipment proceed
as described under section 6.2.
7.9 Using the laser (Fig. 21-23/Item 33)
•
To switch on: Move the ON/OFF switch
of the laser (34) to the “1” position. A laser
line is projected onto the material you wish to
process, providing an exact guide for the cut.
•
To switch off: Move the ON/OFF switch of
the laser (34) to the “0” position.
•
Setting the laser: The laser is adjusted with
the screw (37) and glued in place ex-works.
Further adjustment of the laser during operati-
on is not required. Important. Do not look into
the laser beam.
•
Replacing the battery: Switch off the
laser (33). Remove the battery compartment
cover (36). Remove the batteries and replace
with new batteries (2 x 1.5 Volt Type R03, LR
03 Micro, AAA) Check that the battery termi-
nals are positioned correctly when inserting
new batteries. Close the battery compartment
(35) again.
8. Replacing the power cable
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel to
avoid danger.
9. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before star-
ting any cleaning work.
9.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use cleaning
agents or solvents; these could attack the
plastic parts of the equipment. Ensure that no
water can seep into the device.
