Introduction

MANUFACTURER:

scheppach
Fabrikation von Holzbearbeitungsmaschine GmbH
Günzburger Straße 69
D-89335 Ichenhausen

NOTE:

According to the applicable product liability laws, the
manufacturer of the device does not assume liability for
damages to the product or damages caused by the prod-
uct that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service

technicians,

• Installation and replacement of non-original spare

parts,

• Application other than specified,
• A breakdown of the electrical system that occurs due

to the non-compliance of the electric regulations and
VDE regulations 0100, DIN 57113 / VDE0113.

WE RECOMMEND:

Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the user
to become familiar with the machine and take advan-
tage of its application possibilities in accordance with the
recommendations. The operating instructions contain
important information on how to operate the machine
safely, professionally and economically, how to avoid
danger, costly repairs, reduce downtimes and how to in-
crease reliability and service life of the machine.
In addition to the safety regulations in the operating in-
structions, you have to meet the applicable regulations
that apply for the operation of the machine in your coun-
try. Keep the operating instructions package with the ma-
chine at all times and store it in a plastic cover to protect
it from dirt and moisture. Read the instruction manual
each time before operating the machine and carefully
follow its information. The machine can only be operated
by persons who were instructed concerning the opera-
tion of the machine and who are informed about the as-
sociated dangers. The minimum age requirement must
be complied with.
In addition to the safety notes contained in the present
operating instructions and the special regulations of your
country, the generally recognized technical rules for the
operation of machines must be observed.

Legend of Fig. 1

1 Start button

2 Handle

3 Locking lever

4 Motor

5 Saw blade

6 Moving saw blade guard

7 Base

8 Table insert

9 Rotary table

10 Workpiece clamp

11 Housing / base joint

12 Dust bag

13 Stationary saw blade guard

PKS 1500 A1

Scope of delivery

Mitre saw

Dust bag

Workpiece clamp

Tool for changing the saw blade –

6mm hex key

2 work piece supports

Support stand

2 batteries (AAA)

2 carbon brushes

Operating instructions

Technical Data
Dimensions L x W

x H mm

690 x 550 x 440

Rotary table ø mm

385 x 150

Table height mm

Saw blade Ø mm

210/30/2,6

Number of teeth

Speed rpm

5000

Cutting speed m/s

Pivot range

2 x 45°

Tilt angle

45°

Double mitre

45° x 45°

left

Catch positions

45°, 30°, 22,5°, 15°, 0°,

15°, 22,5°, 30°, 45°

Weight kg

7,7

Cross-cutting data
Max. cut depth

90°/45°

60 / 35 mm

90°/90°

120 x 60 mm

90°/45°

80 x 60 mm

45°/90°

120 x 35 mm

45°/45°

80 x 35 mm

Drive
Motor V/Hz

220-240~ / 50

Rated input W

S6 25% 1500W

Technical changes reserved!

*S6, continuous operation periodic duty.
Identical duty cycles with a period at load followed by a period at
no load. Running time 10 minutes; duty cycle is 25% of the running
time.

The work piece must have a minimum height of 3mm
and a minimum width of 10 mm.
Make sure that the workpiece is always secured with
the clamping device.

Information about noise development
The noise levels of this machine during operation are as
follows:
L

: 99.6dB(A) K=3dB(A)

: 112.6dB(A) K=3dB(A)

Vibration: 4.51m/s

K=1.5m/s

Warning: Noise can have serious effects on your health.
If the machine noise exceeds 85 dB (A), please wear
suitable hearing protection. If the electrical connection
