63 GB/MT
Use / Use of accessories
and the working conditions and can be deter-
mined by means of a practical test.
The table below shows some recommended
settings (for guidance only and given without
liability) for a number of common applications.
The accessories mentioned may not all be sup-
plied as standard with the product. Sawing stone
is only permitted with the use of a cutting guide
(accessory).
Preselected rotation speed:
Material Application Tool Setting
Plastic,
varnish Polishing Lambswool
bonnet 1
Fine finish Felt polishing
disc 1
Metal Fine finish Buffing disc 1
Paint
removal Sanding sheet 2-3
Wood,
metal Brushing,
derusting Cup brush,
sanding sheet 3
Metal,
stone Grinding /
abrading Grinding disc 4-6
Metal Roughing /
grinding Roughing /
grinding disk 6
Stone Cutting Cutting disc
and cutting
guide 6
© Changing a disc
½
Always wear protective gloves
when changing cutting or roughing /
grinding discs.
˽ Press the spindle lock button 9 only after the
mounting spindle 7 has reached a standstill,
Fig. A.
˽ Press the spindle lock button 9 to block the
drive.
˽ Release the clamping nut 6 using the spanner
11 , Fig. B.
˽ Place the roughing, grinding or cutting disc on
to the mounting flange
8 with its labelled side
facing towards the device.
˽ Then replace the clamping nut 6 , with its
raised side facing upwards, on to the mounting
spindle
7 .
˽ Press the spindle lock button 9 to block the
drive.
˽ Tighten the clamping nut 6 again with the
spanner 11 .
Note: Replace a new disc immediately if it runs
unevenly or vibrates after being exchanged.
˽ After replacing a disc let the device run under
no load for 30 seconds as a safety check.
Look out for unusual noises or generation of
sparks.
˽
Check that all the fastenings are correctly
attached.
˽
Pay attention to see that the arrow showing the
direction of rotation on the cutting or roughing /
grinding discs (including diamond cutting discs)
corresponds with the direction of rotation of the
device (see arrow on the head of the device).
© Use of accessories
© Cutting / roughing discs
You can use the following cutting or roughing/
grinding discs with this device:
Dimensions:
ø 125 x 22,2 mm
to max. 6 mm thick
(depressed centre)
Speed: min. 12000 rpm
Circumferential speed: 80 m / sec
ø 125 x 22.2 mm
to max. 6 mm thick
(depressed centre)
12000 rpm
80 m / sec
© Flap discs for metal
Dimensions: ø 125 mm
Speed: min. 12000 rpm
