41 GB
Checking the battery status
To check the battery status, press the button for
the rechargeable battery LED 2 (refer to main
diagram). The status or the remaining power
will be displayed in the rechargeable battery
LED
3 as follows:
RED / ORANGE / GREEN = maximum charge /
performance
RED / ORANGE = medium charge / performance
RED = low charge – recharge battery
Changing tools
Your cordless drill / screwdriver has a fully automat-
ic spindle lock
.
Once the motor has come to a halt, the drive shaft
is automatically locked, so that the chuck
11 can
be opened simply by turning it .
After you have inserted the required bit and fixed it
in place by turning the chuck
, you can immedi-
ately continue working. The spindle lock releases
itself automatically when the motor is started (by
operation of the ON / OFF switch
5 ).
2 Gear Drive
Note: Move the gear selector switch 1 only after
the device has come to a standstill.
In the first gear (Gear selector switch 1
in Position: 1)
you achieve a speed of up to approx. 400 rpm and a
high torque. This setting is suitable for all screwing tasks.
In the second gear (Gear selector switch 1
in Position: 2)
It achieves a speed of up to approx. 1300 rpm, for
the carrying out of drilling tasks.
Torque control / drill step
You can use the torque control / drill step 10 to
adjust the torque. When the value of the torque
setting is reached, the clutch disengages the drive
connection to the chuck.
Select a low setting for small screws, soft work
material.
Select a high setting for large screws, hard
work materials and for the extraction of screws.
For drilling work, select the drill setting by putting
the torque control / drill setting into the position.
For drilling tasks, also push the gear selector
switch 1 to the front (Position: 2).
Preparing the tool for use
Changing the direction of
rotation / unlocking the device
Unlock the device and change the direction of rota-
tion by pressing the rotational direction switch
4
to the right or to the left.
Switching ON / OFF
Switching on:
To start the appliance squeeze on the ON /
OFF switch 5 and then keep it pressed down.
The light 9 comes on with a slightly or fully
pressed ON / OFF switch 5 and illuminates
the working area in poor lighting conditions.
Switching off:
To stop the appliance, release the ON / OFF
switch 5 .
Changing the rotational speed:
The ON / OFF switch
5 has a variable speed
control. Light pressure on the ON / OFF switch 5
causes the device to operate at a low speed. In-
creasing the pressure increases the speed.
Activating the lock
Press the rotational direction switch 4 into the
middle position. The ON / OFF switch 5 is
now blocked.
Before first use / Preparing the tool for use
