32
GB MT
General description
The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.
Contents
Unpack the appliance and check that it is
complete:
The appliance is supplied with the motor
head fitted ( 1). To remove the motor
head, open the securing clips ( 9).
1 Motor housing
2 Carrying handle
6 Waste container
7 4 feet with castors and acces-
sory fittings
12 3-part vacuum tube
13 Vacuum hose
15 Foam filter
16 Material filter (already mounted)
17 Paper filter bag
18 Floor nozzle with
20 Crevice nozzle
6 cross-head screws
Instruction Manual
Dispose of the packaging material properly.
Description of operation
The wet and dry vacuum cleaner is
equipped with a robust plastic container
for waste collection. The castors make the
appliance very easy to manoeuvre. The
suction flow is switched off by a float dur-
ing wet vacuuming once the waste tank is
full. The appliance is also equipped with a
blower function.
The following describes the function of the
operating parts.
Overview
Housing
1 Motor housing
2 Carrying handle
3 On / off switch
4 4 attachment ports for accesso-
ries
5 Suction connection
6 Waste container
7 4 feet with castors and acces-
sory fittings
8 Mains cable
9 Locking clips
10 Blower connection
11a Cable holder on carrying handle
11b Cable holder on dirt container
(see also )
Accessories
12 3-part vacuum tube
13 Vacuum hose with
14 Handle component
Filter
15 Foam filter for wet vacuuming
16 Material filter for dry vacuuming
(already mounted)
17 Paper filter bag for vacuuming
fine dust
Nozzles
18 Floor nozzle with
19 Turnable insert attachment
with brush and rubber lip, for
vacuuming carpets and smooth
surfaces
20 Crevice nozzle
