4. Proper use
The cable hoist is designed for lifting and
lowering loads in enclosed areas
commensurate with the machineʼs capacity.
The equipment is to be used only for its
prescribed purpose. Any other use is deemed
to be a case of misuse. The user / operator
and not the manufacturer will be liable for any
damage or injuries of any kind caused as a
result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
5. Technical data
Voltage (V) 230 V ~ 50 Hz
Rated current (A) 2.2
Power consumption (W) 500
Operating mode S3 20%:10 min
Rated load (kg) 125 / 250
Lifting height (m) 11.5 / 5.7
Rated speed (m/min) 8 / 4
Diameter of steel cable (mm) 3.0
Tensile strength of the steel cable
(N/mm²) 1870
Insulation class B
Protection class IP24
Drive unit class M1
Net weight (kg) 10.5
Operating mode S3 – 20% - 10 minutes: S3 =
Intermittent mode without influencing the
starting process. This means that the
maximum operating period over a time of 10
minutes is 20% (2 minutes).
6. Before starting the equipment
Before you connect the equipment to the
mains supply make sure that the data on
the rating plate are identical to the mains
data.
Always pull out the power plug before
making adjustments to the equipment.
The cable hoist is not suitable for
transporting hot and/or molten materials nor
is it suitable for use at low temperatures or
in environments subject to intensive
weathering.
It is in mechanical group M1.
The service life of the cable hoist is
approximately 8000 cycles (excluding
wearing parts). When the hoist has
completed 8000 cycles, all its mechanical
parts must be checked and overhauled.
Read and absorb the operating instructions
before you use the cable hoist.
Ensure that the operator knows how the
machine works and how it should be
operated.
The user must always operate the
equipment as set out in the operating
instructions.
The cable hoist is not designed for
continuous operation. Its mode of operation
is: Intermittent mode without influencing the
starting process.
The rated capacity of the machine does not
vary due to the position of the load.
6.1 Unpacking
After opening the packaging, inspect the
equipment, the steel cable, the hook, the lever
for maximum cable length and the automatic
stop mechanism lever for signs of possible
transit damage.
6.2 Assembly (Fig. 5)
The cable hoist is fitted with two fastening bars
(1) with which it has to be fastened to a
rectangular tube / swing arm. The dimensions
of the rectangular tube / swing arm must
conform with the size of the fastening bars (1)
and must be capable of supporting twice the
rated load. We recommend that you seek
