Connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the other
RJ-45 connector into the station’s network adapter. Power on the
switch and then system is ready.
For cable selection, refer to the following table.
In making a switch interconnection, you could use any port to connect
another switch with straight or crossover cable. As all the ports support
auto MDI / MDI-X function, using a straight cable to make a
switch-to-switch connection is allowed.
For cable selection, refer to the following table：
4
Network Speed
Cable Type
Max. Length
10Mbps
Cat. 3, 4, 5 UTP/STP
100 meters
100Mbps
Cat. 5 UTP/STP
100 meters
1000Mbps
Cat. 5 UTP/STP
100 meters
