21 13 / 16 " (554mm)
15 15 /
16
"
(404mm)
21 9 / 16 "
(548mm)
41 1 / 4 "
(1047mm)
41 13 / 16 "
(1063mm)
23 13 /
16
" (605mm)
25 5 /
8
" (650mm)
26 3 /
4
" (680mm)
25 1 /
16
" (637mm)
Operating Instructions
D
IMENSIONS
& S
PECIFICATIONS
:
Figure 1: Dimensions of Maxx.
Table 1: Maxx Specifications.
Testing Standard Frequency Voltage
ASTM 1509-04 60 Hz 110 - 120 V
Fuel type Current Max Power
wood pellets - 6mm (1⁄4”) dia. 3.6 Amps 432 Watts
Description Hopper Capacity Consumption on Low
Residential Wood Pellet Heater up to 130 lb (59 Kg) 1.7 lb/hr (0.77 Kg/hr)*
Weight (with full hopper) Consumption on High
455 lb (206 Kg) 7.6 - 8.3 lb/hr (3.45-3.76 Kg/hr)*
*Note: Consumption will vary with the type of fuel used.
