Euro-Pro POWERPRO GI468H - Manual (Page 5)

OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
The PowerPro Iron is equipped with an
auto shut-off. The auto shut-off switches
the iron off if it has been left standing
unmoved in any position (sideways, flat or
upright) for approximately 7-9 minutes. A
red light on the LED display panel will
flash when the iron switches itself off.
(Fig. 6) To switch the iron back on, just
shake the iron side-to-side several times.
Fig. 6
Flash
AUTO SHUT-OFF SELF CLEANING This appliance is for HOUSEHOLD USE
ONLY and may be plugged into any
120V AC polarized electrical outlet. Do
not use any other type of outlet.
Fig. 1
NOTE: Because of the soleplate design,
ordinary tap water may be used with this
iron. However, in very hard water areas,
we recommend using distilled or
demineralized water.
WARNING : Never fill the iron
with fabric conditioner, starches
or any other liquid, as these will
damage the steam mechanism. Do
not use contaminated water.
1. Open the water filling inlet cover.
Holding the iron at a slight angle,
pour water slowly into the water
filling inlet. See figure 1. Fill tank to
desired level or to the “MAX” water
level marking using the water filling
flask. (When the iron is upright, the
see-through water tank allows you to
gauge the amount of water.) DO
NOT overfill the tank. When finished
filling the iron with water, close the
water inlet cover before continuing.
It is important to “Self Clean” the iron at
least every two weeks to remove scale,
calcium, etc. The harder the water, the
more often the iron should be self
cleaned.
FABRIC & TEMPERATURE
INDICATORS
Press on the Electronic Temperature
Control to select the desired fabric
setting. The red lights at the left of the
LED Display Panel will light up.
At the same time, the temperature
indicator lights on the right side of the
LED Display Panel will start to flash.
They will stop flashing when the iron
reaches the selected temperature.
Fig. 7
1. Set the variable steam control to any
steam position.
2. Fill the water tank up to the “MAX”
level.
3. Stand the iron on its heel. Plug the
iron into the electrical outlet.
4. Press the electronic temperature
control button until you get the
“MAX” temperature setting on the
display panel and wait until the iron
heats up and temperature setting
light stops flashing.
5. Turn the variable steam control all the
way to the right to the self-cleaning
position and hold the iron horizontally
over the sink. (Fig. 7).
6. Boiling water and steam will now be
ejected from the holes in the
soleplate. The impurities and scale
are washed away with it.
7. Move the iron back and forth as this
happens.
8. If there is any water left in the water
tank after the iron stops steaming,
just empty the remaining water in a
sink following the instructions for
emptying the iron.
9. Turn the variable steam control to
the “0” position when the water tank
is empty.
10. Place the iron back upright on its
heel to cool down before storing.
DRY IRONING
For dry ironing, turn the variable steam
control dial all the way to the right to “0”.
This will cut off the steam flow if water is
in the water tank. All marked fabric
settings on the LED Display Panel can
be used for dry ironing.
1. Plug the cord into a polarized, 120V
AC electrical outlet. The power “ON”
light will come on, indicating that the
iron is receiving power.
2. Press on the electronic temperature
control button to select the desired
fabric/temperature setting. Turn the
variable steam control to “0”.
(See “Ironing Guide” for a guide to
temperature selection.)
3. Place iron on its heel (on a stable,
protected surface) while iron is
warming to desired temperature.
EMPTYING THE IRON
1. Always empty iron after each use.
2. When finished using the iron, turn
the variable steam control to “0” and
press the electronic temperature
control button until the power light is
lit.
3. Unplug the iron from the electrical
outlet.
4. Turn the iron upside down over the
sink with the tip pointing downward
and allow the water to flow from the
opening.
5. Place iron upright and allow to cool
before storing.
2. Plug the cord into a polarized, 120V
AC electrical outlet.
3. Press on the electronic temperature
control button to select the desired
fabric and temperature setting. Turn
the variable steam control dial to
the desired steam setting. (See
“Ironing Guide” for a guide to
temperature selection.)
STEAM IRONING
CAUTION DO NOT aim iron at
face, towards yourself, or
anyone else while using or adjusting
steam. Burns or serious injury may
occur.
WARNING Before filling the iron
with water, be sure the iron is not
plugged into the electrical outlet. The
iron may be filled with water while it
is hot.
CAUTION TO PREVENT THE
RISK OF BURNS, use caution
when filling iron with water. Burns
can occur from touching hot metal
parts, hot water, or steam.
CAUTION Use caution when
emptying the iron. Burns may
occur from touching hot metal
surfaces, hot water or steam.
7
4
