4
Introduction
Chapter 1
Embedded and Industrial Computing
Chapter 1:
Introduction
Thank you for choosing the VES-8X6. The VES-8X6 is
Lanner’s flagship Micro ATX COM Express Type 6 carrier
board. It is a standard Micro ATX size carrier board which
allows embedded application developers to deploy
their applications quickly on the COM Express modular
platform.
This carrier board has the following highlighted features:
Expansion Interfaces from Module
-Mini-PCIe card with SIM card slot
-VGA, LVDS, HDMI, and DisplayPort
-USB 2.0 (6x; 2 in pin headers, 4 in external type A
connectors), upto USB 3.0 (4x in external type A
connectors)
-PCI Express (1x PCIex4, 1xPCIex16, 1xPCIex1)
-COM (1x RS-232/422/485, 1x RS232), and GPIO (4 input,
4 output)
-Keyboard/mouse
-SATA (4x)
-LPT (1x)
-Line-in, Mic-in, Line-out, SPDIF, CD Audio-in (provided by
Realtek ALC892)
Outline Dimension
243.84 mm x 243.84 mm
Operating Temperature
0 ~ 60°C (32 ~ 140°F)
Storage Temperature
-20 ~ 80°C (-4 ~ 176°F)
Relative Humidity
0% ~ 90% Relative Humidity, Non-condensing
System Specifications
Ordering Information
VES-8X6 COM Express® R2.0 Type 2 Module with Intel® Atom TM D2550
CPU and NM10 Chipset
System
Form Factor Micro-ATX
BIOS
Carrier Board BIOS Socket
(Enable/ Disable by 2-pin Jumper)
I/O Chip Nuvoton NCT6776F
Expansion 1 PCIex16, 1 PCIex4, 1 PCIex1, Mini-PCIe card
I/O
MIO
4 x SATA, 1 x LPT, 1 x RS-232, 1 x RS-232/ 422/ 485,
1 x K/B, 1 x Mouse
USB Connector 6 x USB (Up to 4 x USB 3.0)
DIO 8-bit GPIO
External I/O Connector
PS/2 Mouse (Mini-DIN) & PS/2 KB (Mini-DIN) •
COM1 (DB-9) over HDM •
VGA (DB-15) over DisplayPort •
2 Dual Deck USB ports •
2 RJ45 over Dual USB •
3-Ports Audio Jack •
Internal I/O Connector
LVDS Connector (HIROSE DF13-40DP-1.25V) •
USB: One 5 x 2, pitch 2.54mm Header •
COM: One 5 x 2, pitch 2.54mm Header •
(RS-232/ 422/ 485 & Pin-9 5/ 12V Set by
Jumper)
LPC: One 7 x 2, pitch 2.00mm Header •
CPU Fan: One 3 x 1, pitch 2.54mm Header •
System Fan: Two 3 x 1, pitch 2.54mm Header •
LPT: One 13 x 2, pitch 2.00mm Header •
Floppy: One 17 x 2, pitch 2.54mm Header •
Carrier Board Power: One Switch Button •
Carrier Board Switch: One Switch Button •
GPIO: One 5 x 2, pitch 2.54mm Header •
Power Connector: ATX, One 12 x 2-pin & 2 x •
2-pin (12V Aux Power) Connector
Miscellaneous Setting Connector: One 13 x 2, •
pitch 2.54mm Header (Including Power/Reset
Switch, Power/SATA/Suspend LED, K/B Locked,
Speaker-out, Case Open Detection, Thermal
Detection, LCD Brightness Setting)
Audio
Audio Codec Realtek ALC892 Supports 7.1-CH Audio
Audio Interface Line-in, Mic-in, Line-out, SPDIF, CD-in
Mechanical & Environmental
Power Type AT / ATX
Operating Temperature 0 ~ 60°C (32 ~ 140°F)
Storage Temperature -20 ~ 80°C (-4 ~ 176°F)
Operating Humidity 0% ~ 90% Relative Humidity, Non-condensing
Size (L x W) 243.84 mm x 243.84 mm
Weight 0.5 Kg (1.10 lbs)
Supported COM Express CPU Modules
VES-270
COM Express® R2.0 Type 6 Module with Intel®
Core TM i7 / i3 CPU and QM77 Chipset
Ordering Information
VES-8X6 Micro ATX COM Express® Type 6 Carrier Board
