5
Hardware Setup
Chapter 2
Network Application Platforms
Chapter 2:
Hardware Setup
Preparing the Hardware Installation
To access some components and perform certain service
procedures, you must perform the following procedures
first.
WARNING: To reduce the risk of personal injury,
electric shock, or damage to the equipment,
remove the power cord to remove power from the
server. The front panel Power On/Standby button
(if there is one) does not completely shut off
system power. Portions of the power supply and
some internal circuitry remain active until power
supply is removed.
Unpower the FW-6432 and remove the power cord. 1.
Unscrew 2 screws from the two sides and two screws 2.
on the back of the top cover of the FW-6432 System.
Slide the cover backwards to open it. 3.
Installing a CompactFlash Card
FW-6432 provides one CompactFlash slot slot. Follow the
procedures bellow to install a CompactFlash card.
Align CompactFlash card and the card slot with the 1.
arrow pointing toward the connector.
Push the card to insert into the connector.
2.
