Laney, Nx t, Operating instructions – Laney NEXUS-TUBE User Manual
Page 19
Laney
OPERATING INSTRUCTIONS
N
X
T
Page 19 /24
8
5
1
5
Refer to Labels for tube ID & Grade etc
KEY
1.
NXT Chassis Assembly
2.
M5 x 35 Csk Rsd Posi (Pointed tip)
Pt No.10260
3.
No8 x 30 Csk Posi Screw
Pt No.007194
4.
M6 x 30 Button Head Socket Screw
Pt No.007287
0
5.
Bar Handle Steel/Plastic 90 top
Pt No.007262
6.
M6 Finishing Bush
Pt No. 007286
7.
15mm Posi Pan Screw
Pt No.007197
8.
NXT Rear Grill
Pt No.007285
