Electric
Water
Warewashing
66″ Single Tank Conveyor Dishwasher
without
Built In Hot Water Booster WT66
Inlet Water supply pressure:
22 – 102 psi (150 – 700 kPa)
Inlet Cold Water Supply Temperature
for Pre Wash Tank:
39-59 °F (4-15 °C)
Inlet Water Supply Temperature
Rinse circuit:
194 °F (90 °C)
Wash tank:
80 – 140 °F (27 – 60 °C)
Inlet Water supply hardness:
4 – 8 gpg (7-14 °fH) max
Incoming Cold Water line size
Pre wash:
G 3/4
″
Incoming Hot Water line size
Wash tank:
G 3/4
″
Rinse circuit:
G 3/4
″
Drain line size
Pre wash section:
G 1-1/2
″
Wash/rinse section:
G 1-1/2
″
Water consumption: Gallons/hr:
83.2 gal/hr (315 liters)
Water consumption/rack:
0.4 gal/rack (1.5 l/rack)
Pre wash temperature:
< 105 °F (<40 °C)
Pre wash tank size:
11.8 gal (45 liters)
Pre wash pump power:
0.5 hp (0,37 kW)
Pre wash pump water flow:
39 gal/min (150 l/min)
Wash temperature:
160 – 172 °F (71-78 °C)
Wash tank size:
26 gal (100 liters)
Wash pump power:
2 hp (1.5kW)
Wash pump flow rate:
118.9 gal/min (450 l/min)
Rinse temperature:
180 – 194 °F (82-90 °C)
Rinse pump power:
0.4 hp (0.32 kW)
Rinse pump water flow:
1.32 gal/min (5 l/min)
Initial fill Hot Water requirements:
26 gal (100 liters)
Initial fill Cold Water requirements:
11.8 gal (45 liters)
Supply voltage:
534094 (WT66CL208)
208 V/3p/60Hz
534095 (WT66CR208)
208 V/3p/60Hz
534096 (WT66CL240)
240 V/3p/60Hz
534097 (WT66CR240)
240 V/3p/60Hz
Machine requires one electrical connection.
Max. Current absorbed:
208 V/3p/60Hz
64A (21 kW)
240 V/3p/60Hz
57.5A (21 kW)
Exhaust Requirements
Unit supplied as standard with extended vent hoods
(can be removed during installation if not required).
Exhaust extraction not more than
177 CFM (300 m³/h)
Refer to installation diagram for minimum exhaust hood
installation height .
Key Information
Productivity racks per hour
200 racks / 3600 dishes
(max speed):
(average 18 dishes per rack)
Productivity racks per hour
130 racks / 2340 dishes
(min speed):
(average 18 dishes per rack)
Table to Table connection:
66
″ (
1676
mm)
Number of Tanks:
1
Height with door open:
83-7/16
″ (2119 mm)
Charging hole size (width):
20-7/8
″ (530 mm)
Charging hole size (height):
19-3/4
″ (501 mm)
Net weight:
1012 lb (459 kg)
Shipping weight:
1210 lb (549 kg)
Shipping width:
74-7/16
″ (1890 mm)
Shipping depth:
40-15/16
″ (1040 mm)
Shipping height:
81-1/8
″ (2060 mm)
Shipping volume:
143 cu.ft (4.05 m
3
)
Noise level:
<70 dBA
Unit predisposed to accept external detergent dispensers, detergent
probes and rinse aid dispensers.
