Empire Comfort Systems, Inc. • 918 Freeburg Avenue • Belleville, IL 62222 Page 1 R-4027
SUPERB CAMP STOVE
R-4027
Effective Date July, 2001
WARNING
If not assembled, operated and maintained in accordance with
the manufacturers instructions, this product could expose you to
property damage, personal injury or loss of life from fire,
explosion or asphyxiation.
Read all warnings below.
WARNING
1. This is an outdoor cooking appliance only. Use only outdoors.
2. Do not leave appliance unattended while in use or hot. Never
move cooker while in use or hot.
3. A fire can occur from overheated oil or grease.
4. Oil may heat faster than expected.
5. Use a thermometer to monitor oil temperature.
6. Do not use appliance on or near combustible surfaces, wood
decks, storage sheds, garages, shrubbery, trees, houses, etc...
7. Do not cover the pot when heating oil or grease.
8. Should grease fire occur, turn off the gas and cover the pot with
the lid.
9. Check every fitting for gas leaks before each use.
10. Never stand over burner while lighting; this could result in serious
injury. Carefully follow lighting instructions.
11. This cooker is equipped to operate on propane (LP) gas only from
a refillable cylinder certified by DOT (Department of
Transportation).
12. Keep children and pets at a safe distance.
13. Never place empty containers over an open flame.
14. Do not attempt to change valve depth into burner or reassemble
parts.
15. Never store propane tank in an enclosed area. If cooker is stored in
doors after use, disconnect the propane tank for outdoor storage.
16. The regulator and hose assembly provided with this cooker must
be used, no substitutions. Other regulators or no regulator used at
all could result in dangerous gas leakage and improper burner
performance.
17. Never install or remove the propane tank while cooker is in use or
too hot to touch.
18. Always inspect hose kit before each use. Protect hose from cuts,
heat or abrasions. Never use a hose that indicates signs of cracking
or damage.
19. Never allow hose to contact any part of the cooker while in use or
still hot. Place propane tank from cooker so that the hose length
will not be in the way. Keep all connections and fittings clean,
replace any damaged parts.
20. Never store the propane tank near high heat, open flames, direct
sunlight or where high temperature exist.
21. Never use a flame to check for gas leaks. A gas detector fluid or
soapy dishwashing solution may be applied on the fittings. If
bubbles appear, indicating a gas leak, turn off gas supply and
retighten fittings.
22. Under no circumstances should any alterations or repairs be made
to the burners, valve and controls.
23. A teflon tape or paste must be used on pipe threads before making
the hose connection.
This camp stove is equipped with a hose and regulator to accommodate
a disposable propane cylinder. To connect to a larger propane cylinder
use Part Number, SHK-4 hose kit.
To Ignite Burner
Your camp stove is equipped with an electronic ignition to light the
burners.
Attach brass fitting on hose to the pipe outlet on stove using teflon tape
or paste on pipe threads. Tighten securely with wrench. Make sure that
control valves on the stove are in the OFF position. Screw the liquid
propane disposable cylinder (not included) into the outlet on regulator.
Hand tighten securely. Open control valve on regulator. This activates
the fuel into the cylinder. Open control knob on one gas valve (valve is
push to turn). Immediately turn piezo ignition clockwise to deliver
spark to burner. The second burner is lit in the same manner. It may take
several sparks for burner to ignite.The flame pattern on the burner is
controlled by the regulator valve and control knob on the stove. If the
stove is wet, the ignitor may not spark. A fireplace match or a long nose
lighter can be used to ignite burner. Never let gas build up in burner. If
burner does not light, turn off control knob immediately.
To Clean
The porcelain enameled grates can be removed by pulling upward on
grate. The main top can be removed by unscrewing the four corner
screws. Clean frequently to avoid grease accumulation and possible
grease fires.
To Store
Remove propane cylinder from regulator and replace plastic cap on the
cylinder. Store camp stove in a covered bag or container to avoid the
accumulation of dust, cobwebs, etc.
OUTFITTERS SERIES
Model Number
CS-200W
(9,000 Btu per Burner)
